CAUTION: Use extreme caution of setting your regulator psi
over 28psi. Use the calculators!
To adjust pressure, pull red regulator knob straight out and
turn clockwise to increase pressure and counter-clockwise
to decrease pressure. Push regulator knob in to lock the
pressure setting.
A - CO2 tank pressure (gas remaining)
B - Gas line pressure (adjusted with corresponding
regulator knob)
C - Gas line cut-off switch (shown here in closed position)
A
BB
C
