4.6 CVs Read out
Reading-out the decoder is not a programming option, but it is an essential feature
for checking the programmed settings. The Navigator supports this read-out
procedure which helps to easily check the individual settings. You will nd the
corresponding information in the operating manual of your digital control unit.
Press the key
M3
of your Navigator to enter the main menu. Select “Decoder
Progr.” by pressing
M1
and conrm by pressing
M2
. Select “Read-out CV” by
pressing
M1
and conrm by pressing
M2
to enter the CV Programming menu. You
can now select the “CV No.” by entering the respective number (e.g. 32). Now enter
the requested “Value” and conrm it by pressing
M2
.
By pressing the key
M3
, you will return to the Navigator’s regular mode of function.
4.7 Resetting CVs:
By assigning the value 55 (addresses) and 77 (special functions) to CV7, you
can restore the default settings. This only works in the programming mode “CV
programming”.
5. CV-Values
CV DESCRIPTION DEFAULT RANGE NOTE
2** Programming lock 77, 0 77, 0
Protection against
unintended programming
0 = Programming lock
77= Programming re-locked
7 Software Version (10) --- Read only
7 Decoder Reset --- 55,77
55 = Address reset
77 = Function reset
8 Manufacturer ID 123 --- Nur Lesbar
31 Address „high“ 0 0 .. 7 chapter 4.4
32 Address „low“ 1 0 .. 255 chapter 4.3
50 Switch direction 0 0, 1
Reversing switch direction
51 a: Special functions 67 65 ..79 appendix 1
52 b: Special functions 67 65 ..79 appendix 1
75
Switch opposite direction
automatically
0 0 .. 255
holding time at intervals
of 0.25 seconds
** Prior to programming, you must set CV2 to the value 77 manually. After successful
programming and testing, CV2 must be re-locked by setting it to value 0.
