Pilatus PC-24 - Page 47

4 in
( 100 mm )
CARGO
SMALL
BAGGAGE
RESTRAINT
SYSTEM
7.5 in
( 190 mm )
4 in
( 100 mm )
47.2 in
( 1200 mm )
47.2 in
( 1200 mm )
4 in
( 100 mm )
9.8 in
( 250 mm )
47.2 in
( 1200 mm )
LARGE
BAGGAGE
RESTRAINT
SYSTEM
CARGO
CARGO
47.2 in
( 1200 mm )
ICN-PC24-A-A15000000-A-S4080-05865-A-000-01
Figure 1-4-2: Cargo / Baggage Clearance
Section 1 - Ground Handling
Ground Servicing Guide Report No: 02484
Issue date: Apr 29, 2020
Page 1-4-4
PC24-A-A15-00-0200-00A-160A-A
