DO
WEL FEED BOWL
1
G2154
BOWL CLOCKWISE RO
TATION
G2152
BOWEL COUNTER CLO
CKWISE ROTA
TION (USED IN 2
BOWL OPTION ON
LY)
2
M50430
10 MM DOWEL EXIT
FITURE
M50420
6 MM DOWEL EXIT FI
XTURE
M50410
8 MM DOWEL EXIT FI
XTURE
3
M2305
DOWEL EXIT FIXTURE
22
24
