GLUE / WATER SYSTEM
Convenonal Dowels and Glue
Purging the System
Purge the glue valve before you use the machine to remove air in the system.
Prepare the glue pot.
Place glue in the glue pot. Make sure the pick-up tube goes into the glue when placing the lid back on the pot.
Tighten the pot lid down evenly. Now turn the pot pressure up to 20-30 PSI on the gauge.
Adjust glue pump pressure.
There is a glue pump with a regulator mounted on the side of the machine just above the pressure pot. Run the
glue pump at a pressure that will keep the glue owing properly. You do not need to use excessive pressure on
the system. Recommended glue pump pressure is around 70 PSI. Adjust air pressure to obtain desired amount
of glue ow. For water, the pump is not needed. Pot pressure set to 20 PSI is sucient.
Purge the System.
Place a small container under the clamp bar just in front of the nozzle. Press the purge buon located on the
main screen of the touchscreen. You should start to see glue coming out of the nozzle in about 2-3 seconds.
Run for 5 seconds to make sure the air is out of the line.
This is a sealed system and does not have to be ushed out aer each use.
Flushing the System
Flush the system with hot water once or twice a month, depending on use.
Remove the glue from the pot, clean the pot and ll a small container with hot water. Place the container in the pressure pot.
Place the pick-up tube in the container of water. Install lid and ghten the clamps.
The pressure should be set between 10-15 PSI since water is thinner than glue.
Place another small container under the clamp bar directly in front of the nozzle. Press the purge buon on the main screen. Wa-
ter will come out of the nozzle in about 2-3 seconds. Connue unl water comes out clear. This should only take about 10
minutes to complete.
