Pima Hunter-Pro Series - Hex to Binary Conversion Table; 3 Programming Examples; Displaying a Number

Programming the Hunter-Pro series with a LED keypad 5
5. The hex values A-F are set by pressing the asterisk key ‘
*
’. Each key press
advances the value:
Value A B C D E F
* Key presses 1 2 3 4 5 6
2.2 Hex to Binary conversion table
HEX BIN HEX BIN HEX BIN HEX BIN
0 0000 4 0100 8 1000 C 1100
1 0001 5 0101 9 1001 D 1101
2 0010 6 0110 A 1010 E 1110
3 0011 7 0111 B 1011 F 1111
3. PROGRAMMING EXAMPLES
3.1 Displaying a number
1. Displaying a number that starts with 3:
2. Displaying 6 as the 3
rd
digit of a number:
Account numbers are made of 4 digits, therefor, any account number that has
less than 4 digits must be preceded with zeros. For example: account number
25 will be programmed as 0025.
