Pinnacle Technology OS2CX - Technical Specification

2
2. TECHNICAL SPECIFICATION
Specification of types
Desktop Type OS2CX
Imbedded Type OS2IX
OS2CX
OS2CXK
OS2CXB
OS2CXP
OS2IX
OS2IXD
Basic Features
without display
without keys
without display;
with two keys
with pedestal display
& three keys
with display, pole
& three keys
without display;
with two keys
With separate pole;
display & three keys
Dimension
344.93*262.54
*87.8mm
344.93*262.54
*87.8mm
344.93*343.2
*91.04mm
435.22*344.93
*337.87mm
370*288
*72.4mm
Platter
370*288*
72.4mm
Display pole
415.72*111.57
*86.35mm
Customer/Operator Display
5*8 field LCD
Weighing Capacity (Max.)
6/15kg;15/30kg
Division Value
2/5g;5/10g
Weighing Capacity (Min.)
40g;100g
Tare (Max.)
-5.998kg;-14.995kg
Internal Resolution
1/30000
Accuracy Class
Interface
RS232
Optional
USB、2.4G wifi communication
Power Supply
5V 1A
Working Temperature
0℃-40℃
Working Humidity
5%R.H.-85%R.H.
