INSTALLATION GUIDE

Locate the outlet you wish to wall-mount your EV Flex-AC Charger. The wall-

mount bracket should be installed based on the measurements

(in millimeters) shown below (Picture 3).

STEP 1

1. Wall-mount bracket (item C) screw position

2. Charging handle holster and cable holder (

item E) screw position

Picture 3.

For the recommended installation height of the Pion Power EV Flex-AC

Charger please refer to Picture 2.

Picture 2.

INSTALLATION PROCEDURE

47.5
