VSX-52TX
11
5678
56
7
8
C
D
F
A
B
E
(1) CHASSIS SECTION parts List
(2) CONTRAST TABLE
VSX-52TX/KUXJ/CA and VSX-1014TX-K/KUXJC are constructed the same except for the following:
Mark
No. Description Part No.
1 PRIMARY Assy AWX8384
2 SP/PS Assy AWX8373
3 DIODE Assy AWX8376
4 TRANS 2-1 Assy AWX8372
5 TRANS 2-2 Assy AWX8371
6 TRANS 1 Assy AWX8383
7 VH TR Assy AWX8411
8 TRANS SIDE Assy AWX8417
>
9 Fuse (FU1 : 10A) VEK1029
>
10 Fuse (FU4, 5 : 2.5A) REK1112
>
11 Power Transformer (T1501) ATS7374
>
12 Power Cable VDG1075
13 Flexible Cable (12P) ADD7477
14 Primary Angle 56 ANG7526
15 DSP Shield A V1 ANG7479
16 Cord Stopper CM-22C
17 Under Beam V1 AND7478
18 Trans. Frame 45 ANG7399
NSP 19 Panel Stay V1 AND7066
20 Stabilizer 45 See Contrast table (2)
21 Screw Cover 45A AEC7414
NSP 22 Under Base See Contrast table (2)
23 PCB Mold AMR2534
24 Locking Card Spacer PNW2917
25 Card Spacer DNK2769
26 Wire Saddle 5S AEC7500
27 Push Rivet AEC7370
NSP 28 Binder (BK-1) ZCA-BK1
NSP 29 Trans. Label V1 AAX8052
30 Screw IBZ30P150FCC
31 Screw ABA7109
32 Screw BBZ30P080FCC
33 Deco Screw ABA7060
Mark
No. Description Part No.
Mark No. Symbol and Description
VSX-52TX
/KUXJ/CA
VSX-1014TX-K
/KUXJC
20
Stabilizer 45
ANG7408 Not used
NSP 22 Under Base 52 ANA7166 Not used
NSP 22 Under Base 1014 Not used ANA7161
