(1) REAR PANEL SECTION parts List
(2) CONTRAST TABLE
VSX-52TX/KUXJ/CA and VSX-1014TX-K/KUXJC are constructed the same except for the following:
Mark
No. Description Part No.
1 12V TRIGGER Assy See Contrast table (2)
2 COMPONENT Assy AWX8358
3S VIDEO Assy AWX8361
4 COMPOSITE V Assy See Contrast table (2)
5 MULTI CH I/O Assy See Contrast table (2)
6 REAR TOP Assy AWX8397
7 OPTICAL-IN Assy AWX8394
8 VIDEO SIDE Assy AWX8366
9AUDIO CONNECT Assy AWX8382
10 MAIN CONTROL Assy See Contrast table (2)
11 REGULATOR Assy See Contrast table (2)
12 DSP Assy AWX8414
13 FM/AM TUNER Unit AXX7172
>
14 Fuse (FU2501, 2502 : 3.15A) REK1114
15 Connector Assy (8P) See Contrast table (2)
16 Flexible Cable (11P) ADD7476
17 Flexible Cable (17P) ADD7478
18 Flexible Cable (10P) ADD7472
19 Rear Panel See Contrast table (2)
20 Card Spacer AEC7502
21 Speaker Sheet V1 AAK8176
22 Hexagonal Screw See Contrast table (2)
23 Screw BBZ30P080FCC
24 Screw BBT30P100FCC
25 Cushion Circle 14B AED7081
Mark
No. Description Part No.
Mark No. Symbol and Description
VSX-52TX
/KUXJ/CA
VSX-1014TX-K
/KUXJC
1 12V TRIGGER Assy
AWX8395
Not used
4 COMPOSITE V Assy AWX8353 AWX8362
5 MULTI CH I/O Assy AWX8410 AWX8352
10 MAIN CONTROL Assy AWX8343 AWX8348
11 REGULATOR Assy AWX8364 AWX8367
15 Connector Assy (8P) ADE7085 Not used
19 Rear Panel 52KU ANC8249 Not used
19 Rear Panel 1014KU Not used ANC8254
22 Hexagonal Screw ABA7078 Not used
