Pioneer AVH-P5200BT Service Manual

AVH-P5200BT/XNUC
91
5678
56
7
8
C
D
F
A
B
E
3
2
3
1
1
1
Fig.5
Fig.4
2
1
2
3
3
3
2
2
2
Remove the screw.
Remove five screws.
Straighten the tabs at two locations indicated
and then remove the Holder.
Remove the three screws.
Disconnect the connector. (Only BT model)
Straighten the tabs at three locations indi-
cated and then remove the DVD Amp Unit.
1
2
3
1
2
3
Removing the Holder and the Panel (Fig.4)
Removing the DVD Amp Unit (Fig.5)
Panel
Holder
DVD Amp Unit
