Pioneer DEX-P99R Service Manual

11
DEH-P945R,DEX-P99R
91 Gear CNV5273
92 Rack CNV5274
93 Lighting Conductor CNV5276
94 Guide CNV5356
95 Gathering PCB CNX2961
96 Mini Jack(CN4602) CKN1015
97 Plug(CN4601) CKS-786
98 Panel Unit CXB2212
99 Arm Unit CXB2215
100 Frame Unit CXB2216
101 Holder Unit CXB2217
102 Arm Unit CXB2218
103 Bracket Unit CXB2598
104 Motor CXM1085
105 ASL Unit CWX2216
106 Screw BSZ30P055FMC
107 Cord CDE5763
108 Plug(CN4501) CKS-784
109 Case CNB2299
110 Case CNB2300
111 Holder MNC9008
112 Holder Assy CZX3172
113 Holder Assy CZX3173
114 Cover CZN6410
115 Remote Control Assy CXB2660
116 Battery Cover CNS5032
117
CD Mechanism Module(H1) CXK5101
118 Chassis Unit CXB2228
119 Switch(S951) CSN1012
120 Switch(S952) CSN1022
121 IC(IC871) NJM78M05FA
122 Trangistor(Q992) 2SD2396
123 Holder CNC8013
124 IC(IC941) PA2024
125 Lamp(IL801) CEL1359
126 •••••
127 Handle CNC5395
128 Spring CBH-865
129 Bush CNV1917
130 Holder CNC8021
131 Holder MNC9009
132 Inverter Unit MWM9026
133 Holder CNC8011
134 Spacer CNM5996
135 Spacer CNM5988
136 Cord Assy CDE5539
137 Guide Unit CXB3234
138 Screw BMZ30P040FMC
139 High Out Unit CWX2215
140 Cord Assy CDE5555
141 Plug(CN4153) CKS1045
142 Plug(CN4152) CKS1613
143 Plug(CN4051) CKS1614
144 Holder CNC8009
145 Holder CNC7556
146 Shield CNC8010
147 Insulator CNM4760
148 Insulator CNM5650
149 Insulator CNM5651
150 Shield CNC6224
151 Shield CNC6274
152 Insulator CNM4610
153 Insulator CNM4814
154 D/D Converter Unit CWM4538
155 Terminal
(CN4001,4002,4003,4004) CKF1023
156 Holder CNC8012
157 Remote Control Assy CZX3218
158 Cover CZN6410
159 Cushion CNM6065
160 Spacer CNM6069
161 Spacer CNM6093
Mark No. Description Part No. Mark No. Description Part No.

Pioneer DEX-P99R Specifications

General

Brand	Pioneer
Model	DEX-P99R
Category	Car Receiver
Language	English
