Pioneer HTP-076 User Manual

12
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Front Panel≫ Rear Panel≫ Remote≫
1. DIGITAL AUDIO IN OPTICAL/COAXIAL jacks: Input TV or AV component
digital audio signals with a digital optical cable or digital coaxial cable.
2. HDMI OUT jacks: Transmit video signals and audio signals with a HDMI cable
connected to a TV.
3. HDMI IN jacks: Transmit video signals and audio signals with a HDMI cable
connected to an AV component.
4. POWER OUT port: You can also supply power (5 V/1 A) to the Streaming
media player connected to the HDMI IN terminal of this unit with a USB cable.
( p32) The playback function of music les and power supply to smart
phones/tablets, or other devices are not supported.
5. Power cord
6. ANTENNA AM LOOP/FM UNBALANCE 75 Ω terminal: The supplied antennas
are connected.
7. AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
8. ZONE B LINE OUT jacks: Output audio signals with an analog audio cable
connected to a pre-main amplier in a separate room (ZONE B).
9. SUBWOOFER PRE OUT jack: Connect a powered subwoofer sold separately
with a subwoofer cable. Up to two powered subwoofers can be connected.
The same signal is output from each of the SUBWOOFER PRE OUT jacks.
10. SPEAKERS terminals: Connect included speakers and subwoofer with
speaker cables. (FRONT L/R terminals of North American models support
banana plugs.)

Pioneer HTP-076 Specifications

General

Coloration	Monochromatic
Apple docking	No
Audio amplifier	Yes
Bluetooth profiles	A2DP, AVRCP
Type	Home audio midi system
Product color	Black
Channels quantity	5.1 channels
Supported radio bands	AM, FM
Preset stations quantity	80
Speaker type	1-way
RMS rated power	450 W
Number of speakers	5
Number of subwoofers	1
Audio decoders	DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital Plus, Dolby Surround, Dolby TrueHD
Optical disc player type	Not included
Video formats supported	-
Tweeter diameter	77 mm
Soundbar speaker RMS power	150 W
Bluetooth version	4.2
HDMI in	4
Digital audio coaxial out	0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	465 W

Weight and Dimensions

Receiver weight	800 g
Subwoofer weight	4600 g
Center speaker weight	600 g
Receiver dimensions (WxDxH)	435 x 321 x 148 mm
Subwoofer dimensions (WxDxH)	230 x 331 x 393 mm
Front speaker dimensions (WxDxH)	90 x 108.5 x 131.5 mm
Center speaker dimensions (WxDxH)	220 x 100 x 97 mm
