Pioneer PDP-425CMX Service Manual

PDP-425CMX
11
5678
56
7
8
C
D
F
A
B
E
(1) PACKING SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-425CMX/LUC5, PDP-42MXE10/LDFK5 and YVXK5 are constructed the same except for the following:
Mark
No. Description Part No.
> 1Power Cord See Contrast table (2)
2 Remote Control Unit
AXD1528
3 Battery Cover AZN2462
NSP 4 Dry Cell Battery (R6P, AA) VEM1031
5 Cable tie AEC-093
6 Speed clamp AEC2051
7 Cleaning Cloth AED1285
8 Remote Control Holder AMR3268
9 Display Stand AMR3545
10 Ferrite Core (for power cord) ATX1031
11 Ferrite Core (for audio cables) CTX1054
12 Screws Set AXX1071
13 Hex hole bolt SMZ80H400FTC
14 Washer WB80FTC
15 Operating Instructions See Contrast table (2)
(English, French, Japanese)
16 Operating Instructions See Contrast table (2)
(English)
17 Operating Instructions See Contrast table (2)
(7L)(CD-ROM)
18 Caution Sheet See Contrast table (2)
19 Caution Sheet ARM1245
20 Caution Sheet See Contrast table (2)
NSP 21 Warranty Card See Contrast table (2)
NSP 22 Warranty Card See Contrast table (2)
NSP 23 Polyethylene Bag See Contrast table (2)
24 Catalogue Bag AHG1310
25 Catalogue Bag S AHG1338
26 Pad BL (FT) See Contrast table (2)
27 Pad BR (FT) See Contrast table (2)
28 Pad BC (FT) See Contrast table (2)
29 Pad TL (FT) See Contrast table (2)
30 Pad TR (FT) See Contrast table (2)
31 Accessory Case See Contrast table (2)
32 Power Cord Case See Contrast table (2)
33 Reinforce Pad (FT) See Contrast table (2)
34 Carton (42FT) See Contrast table (2)
35 Upper Carton See Contrast table (2)
36 Mirror Mat See Contrast table (2)
37 Plasma Caution Sheet See Contrast table (2)
38 Image Caution Sheet See Contrast table (2)
39 Image Stick Caution Sheet See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-425CMX
/LUC5
PDP-42MXE10
/LDFK5
PDP-42MXE10
/YVXK5
> 1Power Cord ADG1215 Not used Not used
15 Operating Instructions (English, French, Japanese) ARD1070 Not used Not used
16 Operating Instructions (English) Not used ARE1419 ARE1419
17 Operating Instructions (7L)(CD-ROM) Not used ARU1001 ARU1001
18 Caution Sheet ARM1201 ARM1201 Not used
20 Caution Sheet Not used Not used ARM1279
NSP 21 Warranty Card ARY1146 Not used Not used
NSP 21 Warranty Card (EU) Not used ARY1149 ARY1149
NSP 22 Warranty Card ARY1146 Not used Not used
NSP 23 Polyethylene Bag AHG-195 Not used Not used
26 Pad BL (FT) AHA2495 AHA2495 AHA2528
27 Pad BR (FT) AHA2496 AHA2496 AHA2529
28 Pad BC (FT) AHA2497 AHA2497 AHA2530
29 Pad TL (FT) AHA2522 AHA2522 AHA2531
30 Pad TR (FT) AHA2523 AHA2523 AHA2532
31 Accessory Case AHC1072 AHC1072 AHC1078
32 Power Cord Case AHC1077 AHC1077 AHC1081
33 Reinforce Pad AHC1079 AHC1079 AHC1080
34 Carton (42FT) AHD3417 AHD3417 AHD3458
35 Upper Carton AHD3418 AHD3455 AHD3461
36 Mirror Mat AHG1284 AHG1284 AHG1327
37 Plasma Caution Sheet ARM1147 Not used Not used
38 Image Caution Sheet ARM1220 Not used Not used
39 Image Stick Caution Sheet ARM1299 Not used Not used
