Pioneer PDP-425CMX - Page 125

PDP-425CMX
125
5678
56
7
8
C
D
F
A
B
E
Not lit
Green: Lit
Reason for SD
MD SD information
Main="1"
SQ-IC
MD SD information
Main="2"
MDU-IIC
MD SD information
Main="3"
RST2
MD SD information
Main="4"
Panel high temeprature
The LED flashes
according to SD
data from the MD.
The LED flashes
according to SD
data from the MD.
The LED flashes
according to SD
data from the MD.
The LED flashes
according to SD
data from the MD.
*1: Detailed information can be obtained by
issuing an RS-232C command (QNG).
Temperature
sensor high
temperature *1
Power supply
voltage 3.3V
detection
Short circuit of
speaker
Failure in module
microcomputer
communications
Failure in main microcom-
puter IIC communications
EEPROM (main control),
EEPROM (VIDEO SLOT),
IC1(VIDEO SLOT),
A/D-PLL, IC6, AUDIO
CONTROL IC,
Extension I/O2
Not used
Not used
Not used
FAN stopped
Abnormal
temperature
Abnormal power
supply voltage
VCC-DOWN1 detection
VCC-DOWN2 detection
LED Display Pattern Remarks
Color
Flashing
Frequency
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
1
2
3
4
5
6
8
9
10
11
12
13
14
15
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
Repeat
*1
*1
Triggered by an REQ_MD signal, a QS2 command is issued to acquire data on the status of the MD.
• After the control program refers to the main shutdown (SD) data echoed back, when a shutdown is found to have been
generated, the green LED flashes the number of times (1-4) specified by the main MD SD data in a burst.
• If a shutdown is generated on the main unit side, the green LED flashes the number of specified times (5-15) in a burst,
as shown in the table below.
• If a shutdown is generated on the MD and main unit sides, MD SD data take priority.
How to cancel an alarm
If power is shut off in response to a shutdown (SD) or power-down signal,
turn the main power off, or unplug the power cord then reconnect it.
After making sure that the red LED goes dark, turn the main power back on.
