Pioneer PDP-425CMX Service Manual

PDP-425CMX
13
5678
56
7
8
C
D
F
A
B
E
(1) FRONT and REAR SECTIONS PARTS LIST
(2) CONTRAST TABLE
PDP-425CMX/LUC5, PDP-42MXE10/LDFK5 and YVXK5 are constructed the same except for the following:
Mark
No. Description Part No.
1 KEY Assy AWW1108
2 LED2 Assy AWW1109
NSP 3 Panel Holder (FT) ANG2840
4 PCB Spacer AEC1947
5 Inner Grip Assy AMR3434
NSP 6 Name Label See Contrast table (2)
7 Serial Sheet AAX3143
8Terminal Label MAIN A (CMX) See Contrast table (2)
9Terminal Label MAIN B (CMX) See Contrast table (2)
10 Terminal Label MAIN C (CMX) See Contrast table (2)
11 Caution Label (CMX) See Contrast table (2)
12 Caution Label See Contrast table (2)
13 Front Case Assy (425CMX) AMB2885
> 14 Filter (FT) AMR3510
15 Control Button (CMX) AAC1559
16 Pioneer Badge AAM1101
17 Control Cover (CMX) AMR3512
18 Rear Case ANE1650
19 Bottom Cover (CMX) ANG2860
20 • • • • •
21 Screw ABZ30P100FTB
22 Screw AMZ30P060FTB
Mark No. Symbol and Description
PDP-425CMX
/LUC5
PDP-42MXE10
/LDFK5
PDP-42MXE10
/YVXK5
NSP 6 Name Label (CMX) AAL2726 Not used Not used
NSP 6 Name Label (MXE) Not used AAL2734 AAL2746
8Terminal Label MAIN A (CMX) AAX3250 AAX3250 AAX3292
9Terminal Label MAIN B (CMX) AAX3251 AAX3251 AAX3293
10 Terminal Label MAIN C (CMX) AAX3252 AAX3252 AAX3294
11 Caution Label (CMX) AAX3253 Not used Not used
12 Caution Label M AAX3304 AAX3304 Not used
12 Caution Label Not used Not used AAX3295
