PDP-425CMX
156
1234
1234
C
D
F
A
B
E
Waveform 32 Waveform 44Waveform 35
Waveform 33-1 Waveform 45Waveform 41
Waveform 33-2 Waveform 46Waveform 42
Waveform 34 Waveform 43
Conditions of signal input
Audio input connector: AUDIO 1 or Video slot card (L ch)
Input signal level: 200mVrms
Input signal frequency: 1 kHz
Volume: Max
