PDP-425CMX
17
5678
56
7
8
C
D
F
A
B
E
(1) MULTI BASE SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-425CMX/LUC5, PDP-42MXE10/LDFK5 and YVXK5 are constructed the same except for the following:
Mark
No. Description Part No.
1 MAIN Assy See Contrast table (2)
2 VSIF Assy See Contrast table (2)
3 Flexible Cable (J219) ADD1342
4 20P Housing Wire (J215) ADX3273
5 20P Housing Wire (J217) ADX3274
6LVDS Cable (J223)
ADX3276 (or ADX3289)
7 Multi Base (CMX) ANA1901
8
Ter minal Panel MAIN (CMX) Assy
ANG2871
9 Slot Spring T130 ABK1032
10 Slot Spring B126 ABK1033
11 Slot Panel 262 (N) ANG2610
12 VIDEO I/F Bracket ANG2858
13 Wire Saddle AEC1745
14 Wire Saddle AEC1797
15 PCB Support AEC1958
16 Rivet AMR1066
17 VIDEO Guide Rail AMR3485
18 VIDEO I/F Sheet AMR3495
19 PWB Sleeve AMR3518
20 • • • • •
21 Screw AMZ30P060FTB
22 Hex Head Screw BBA1051
23 Screw PMB30P100FNI
24 Screw VBB30P080FNI
Mark No. Symbol and Description
PDP-425CMX
/LUC5
PDP-42MXE10
/LDFK5
PDP-42MXE10
/YVXK5
1 MAIN Assy AWW1100 AWW1112 AWW1112
2 VSIF Assy AWW1101 AWW1113 AWW1113
To Next Page
