Pioneer PDP-425CMX Service Manual

PDP-425CMX
23
5678
56
7
8
C
D
F
A
B
E
(1) PANEL CHASSIS SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-425CMX/LUC5, PDP-42MXE10/LDFK5 and YVXK5 are constructed the same except for the following:
2.8 PDP SERVICE ASSY
PDP SERVICE ASSY PARTS LIST
Mark
No. Description Part No.
NSP 1 Panel Chassis (FT) Assy See Contrast table (2)
2 42 SCAN A Assy AWW1071
3 42 SCAN B Assy AWW1072
4 42 ADDRESS Assy AWV2253
5 MD DIGITAL Assy AWV2254
6Ferrite Core ATX1048
7 Flexible Cable (J109) ADD1329
8 Flexible Cable (J110) ADD1330
9 Flexible Cable (J117) ADD1331
10 Flexible Cable (J119) ADD1332
11 Flexible Cable (J120) ADD1333
12 Flexible Cable (J211) ADD1334
13 Wire Saddle AEC1745
14 Flat Clamp AEC1879
15 PCB Support AEC1938
16 PCB Spacer AEC1941
17 Drive Silicone Sheet AEH1095
18 Power Sheet (FT) AMR3521
19 Y Drive Protect Sheet (FT) AMR3525
20 Harness Lifter 18 AEC1980
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-425CMX
/LUC5
PDP-42MXE10
/LDFK5
PDP-42MXE10
/YVXK5
NSP 1 Panel Chassis (FT) Assy AWU1136 AWU1136 AWU1151
Mark
No. Description Part No.
PDP Service Assy 42H6D1 AWU1160
NSP Panel Chassis (FT) Assy AWU1136
Wire Saddle AEC1745 x5
Flat Clamp AEC1879 x9
PCB Support AEC1938 x2
PCB Spacer AEC1941 x22
Harness Lifter 18 AEC1980 x2
Power Sheet (FT) AMR3521
Y Drive Protect Sheet (FT) AMR3525
Caution Label AAX3031 x2
Screw PMB50P150FTC x4
Accessories
Wire Saddle AEC1745 x13
PCB Spacer AEC1941 x4
Harness Lifter 18 AEC1980
Locking Wire Saddle AEC1992 x11
Vinyl Bag S AHG1338
Sheet (FT) AMR3530 x2
Packing parts
Pad 42 Single (T-L) AHA2550
Pad 42 Single (T-R) AHA2551
Pad 42 Single (B-L) AHA2552
Pad 42 Single (B-R) AHA2553
Upper Carton (42 Single) AHD3480
Under Carton (42 Single) AHD3481
Polyethylene Bag AHG1381
Packing Sheet AHG1386
Tray (FT) AHX1158
Cup Spacer (15) ANG2936 x4
Mark
No. Description Part No.
