Pioneer PDP-425CMX - Page 62

PDP-425CMX
62
1234
1234
C
D
F
A
B
E
R3014, R3019 RS1/10SR3902F
R3061-R3066 RS1/8SQ0R0J
R3054, R3056, R3059, R3060 RS1/8SQ103J
R3005, R3006 RS1/8SQ221J
R3003, R3004 RS1/8SQ822J
Other Resistors RS1/10S###J
OTHERS
>
CN3001 SPEAKER TERMINAL 4-P AKE1062
CN3003 CONNECTOR AKM1277
CN3004 CONNECTOR AKM1280
KN3001-KN3003 GROUND PLATE ANK1664
COMMSLOT ASSY
SEMICONDUCTORS
IC2003 MAX3222IPER
IC2001, IC2002 MC74VHCT132ADT
IC2004, IC2005 TC74VHC00FT
IC2006, IC2007 TC74VHC125FT
D2011-D2014 DAN217U
CAPACITORS
C2001-C2007 CCSRCH101J50
C2014, C2015, C2019-C2021 CCSRCH471J50
C2018 CEHVKW470M16
C2009, C2010 CKSRYB104K25
C2008, C2011-C2013, C2016, C2017 CKSRYB104K50
C2022-C2024 CKSRYB104K50
RESISTORS
R2019, R2020 RS1/8SQ0R0J
Other Resistors RS1/10S###J
OTHERS
2005 SCREW ABA1318
2003 RIVET (PLASTIC) AEP-211
CN2001 9P D-SUB SOCKET AKP1213
JA2002, JA2003 6PIN MINI-DIN JACK AKP1254
2004 PROTECT SHEET 92 AMR3401
2002 SLOT PANEL 92 ANG2611
2006 HEXAGON HEADED SCREW BBA1051
2001 SCREW TERMINAL VNE1949
COMMSLOT IF ASSY
SEMICONDUCTORS
IC2301 TC74VHC00FT
Q2301, Q2351 2SC4081
Q2302 DTC144EUA
Q2350 HN1A01FU
CAPACITORS
C2350, C2351 CKSRYB104K25
C2301 CKSRYB104K50
RESISTORS
R2354 RS1/10SR1002F
R2351, R2353 RS1/10SR1202F
R2350 RS1/10SR1502F
R2355 RS1/10SR2201F
R2313 RS1/8SQ0R0J
Other Resistors RS1/10S###J
Mark No. Description Part No.
OTHERS
CN2302 40P SIDE CONNECTOR AKM1347
CN2303 EDGE CARD CONN AKP1252
KEY ASSY
SEMICONDUCTORS
IC2201 PD5719A
Q2201 2SC4081
D2201 1SS355
SWITCHES AND RELAYS
S2201-S2208 ASG1088
CAPACITORS
C2203, C2204, C2208 CCSRCH101J50
C2207 CEHVKW470M6R3
C2206 CKSRYB104K50
C2201, C2202, C2205 CKSRYB472K50
RESISTORS
R2210 RAB4CQ182J
R2204, R2207 RS1/10SR2202F
Other Resistors RS1/10S###J
OTHERS
>
X2201 (3.84MHz) CERALOCK ASS1162
CN2201 3PIN CONNECTOR S3B-EH
LED2 ASSY
SEMICONDUCTORS
Q2406 2SA1576A
Q2403-Q2405 2SC4081
Q2401 HN1B04FU
D2401 S9561
D2402 SPR-39MVWF
CAPACITORS
C2407, C2408 CEHVKW470M16
C2401, C2405, C2409 CKSRYB104K25
C2402-C2404 CKSRYF105Z16
RESISTORS
R2416-R2419 RS1/8SQ130J
Other Resistors RS1/10S###J
OTHERS
CN2401 CONNECTOR AKM1294
42 ADDRESS ASSY
[42 ADR LOGIC BLOCK]
SEMICONDUCTORS
IC1501 PEE002A
COILS AND FILTERS
L1504 CHIP SOLID INDUCTOR QTL1013
CAPACITORS
C1502 (47/6.3) ACH1357
C1557 CCSSCH470J50
C1501 CKSRYB105K6R3
C1509, C1510 CKSSYB102K50
Mark No. Description Part No.
