PDP-425CMX
78
1234
1234
C
D
F
A
B
E
Vertical Frequency (grouping by frequency)
Input Signal Type
(1st character)
(2nd character) (3rd character)
V Frequency group
(response)
Vertical Frequency(Hz)
"3" 58.2 to 63.0
"4" 63.0 to 68.0
"8"
80.0 to 88.5
"7" 73.9 to 80.0
"6" 73.4 to 73.9
"5" 68.0 to 73.4
"–" NO SIGNAL
"?–" OUT OF RANGE
"2"
54.5 to 58.2
"1" 45.0 to 54.5
"C" 28.0 to 45.0
"B" 20.0 to 28.0
Main Screen Size
Main screen size
(response)
Screen size
"2" FULL / FULL 1080i
"3" ZOOM
"A"
2.35 : 1
"9" UNDERSCAN
"6" 14 : 9
"5" WIDE
"1"
4 : 3
"0" DOT BY DOT
Input Signal Type
(response)
Signal Type (state)
PC Signal Input Video Signal Input
Input Signal Type
(response)
Signal Type (state)
"–" NO SIGNAL "–" NO SIGMAL
"?" OUT OF RANGE "?" OUT OF RANGE
"A" 640 × 400/720 × 400 "1" SDTV / 525i (480i)
"B" 640 × 480 "2"
"I" 1152 × 870
"7"
HDTV / 1125i (1035i)
"J" 1152 × 900
"8"
"5"
"6"
HDTV / 1125i (1080i)
"K"
HDTV / 1125p(1080p)
"L"
1280 × 960
1280 × 1024
"N" 1600 × 1200
"M" 1400 × 1050
"C" 848 × 480/852 × 480 "3" SDTV / 625i (576i)
SDTV / 525p (480p)
"D" 800 × 600 "4" SDTV / 625p (576p)
"E" HDTV / 750p (720p)
"F" 1024 × 768
832 × 624
"H" 1152 × 864
"G" 1280 × 768
¶ SIG-Mode Table
The signal mode is displayed in three charecters:
1st character : Resolutin of the input signal ( numerics for the video signals, and alphabetics for the PC signals )
2nd character : Grouping of the Vertical frequencies
3rd character : Main screen size
