PDP-427CMX
7
5678
56
7
8
C
D
F
A
B
E
FRONT FRAME SECTION
ANA2067
Front ChassisU ASSY
(427)
ANA2085
Front Chassis LA ASSY
(427)
ANA2084
Front ChassisR ASSY
(427)
ANG2840
Panel Holder (FT)
ANG2840
Panel Holder (FT)
ANG2840
Panel Holder (FT)
ANG2840
Panel Holder (FT)
No.1
No.1
No.5
No.6
No.7
No.4
(Back side)
No.3
(Back side)
No.2
(Back side)
No.2
(Back side)
No.3
(Back side)
No.4
(Back side)
Front Case Assy
Screw
Protection
Panel
Pioneer Badge
Screw
Screw
Screw
