Pioneer PDP-4300 - 4 th Generation 2 Piece Plasma Quick Reference Chart

4th generation 2 piece PLASMA
Quick Reference Chart
PRO504PU PDP504PU PRO434PU PDP434PU
Service Panel Assy AWU1080, 1108 (1) D AWU1079, 1109 (1) D
Scan IC AN16003A D SN755864APZP D
Power Supply Module AXY1068 D D D
Digital Video Assy
AWV2018, 70
or AWV2110 D D D
Y Drive Assy
AWV2035, 68
AWV2144, 47 D
AWV2022, 66 D
X Drive Assy. AWZ6808
D
AWZ6794, 6840 D
Panel IF Assy. AWZ6768 D D D
Audio Amp Assy AWZ6834 D D D
Panel Sensor Assy. AWZ6795 D D D
Panel LED Assy AWZ6787 D D D
Panel Key Assy AWZ6788 D D D
Key Control Assy AWZ6789 D D D
Panel IR Assy AWZ6790 D D D
HD SP Terminal AWZ6792 D D D
Front Case Assy AMB2804 AMB2763 AMB2783 AMB2779
Hex Hole Bolt SMZ80H400FZB D D D
AC cord ADG1215 D D D
Protect Panel Assy AMR3348 AMR3385 AMR3345 AMR3383
Remote Control AXD1484 AXD1478 AXD1484 AXD1478
System Cable (white/black) ADF1021 or 7, 9 D D D
Service Manual ARP3176
D
ARP3174 D
Owner's Manual
ARB1556 ARE1367 ARB1556 ARE1367
(1) Adjustment varies depending on digital video. SI pending.
