78
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting | Appendix
necessary.
If the unit is installed in a rack or cabinet with colored-
glass doors or if the doors are closed, the remote
controller may not work reliably.
After operating the Multi-zone function, the remote
controller may have switched to the mode for operating
ZONE output audio. Check "Multi-zone" in "Playback" in
the Basic Manual to switch the remote controller back to
the mode for operating in the main room.
Display, OSD
The display doesn't light
The display may go dim while the Dimmer is working,
and may also turn off. Press DIMMER button and
change the brightness level of the display.
Others
Strange noises can be heard from the unit
If you have connected another unit to the same wall
outlet as this unit, this noise may be an effect from the
other unit. If the symptoms improve by unplugging the
power cord of the other unit, use different wall outlets for
this unit and the other unit.
When performing Full Auto MCACC, the message
"Noise Error" appears
This can be caused by a malfunction in your speaker
unit. Check if the unit produces normal sounds.
DRC function does not work
Make sure the source material is Dolby Digital, Dolby
Digital Plus, Dolby TrueHD, or DTS.

Other manuals for Pioneer SC-LX701

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pioneer SC-LX701 and is the answer not in the manual?

Pioneer SC-LX701 Specifications

General IconGeneral
Display-
Product colorSilver
Audio decodersDTS 96/24, DTS-ES, DTS-HD, DTS-HD HR, DTS-HD Master Audio, Dolby Digital Plus, Dolby Surround, Dolby TrueHD
Audio amplifierYes
Apple docking compatibilityNot supported
Receiver typeSurround
Frequency range20 - 20000 Hz
Audio output channels9.2 channels
Dynamic power per channel (4 Ohm)220 W
Power output per channel (1KHz@6 Ohm)185 W
Power output per channel (1KHz@8 Ohm)135 W
Power output per channel (20-20KHz@8 Ohm)- W
HDMI in8
Digital audio optical in3
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeTerminals
Speakers connectivity typeBinding post
Audio formats supportedAAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version4.1
Bluetooth profilesA2DP, AVRCP
Supported radio bandsAM, FM
Preset stations quantity40
Internet radio services supportedPandora, TuneIn
Card reader integratedNo
AC input voltage220-230 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.15 W
Power consumption (typical)310 W
Supported video modes1080p, 2160p
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth441 mm
Width435 mm
Height185 mm
Weight15300 g
