Pioneer SC-LX73 Service Manual

8
SC-LX83
1
2 3 4
A
B
C
D
E
F
1
2 3 4
R9616 RS1/16SS221J Not used
R9840 RS1/16SS222J Not used
R9521, R9637 RS1/16SS330J Not used
R9805 RS1/16SS333J RS1/16SS183J
R675, R681, R682, R1846 RS1/16SS470J Not used
R1847, R1865, R1887, R1903 RS1/16SS470J Not used
R9126, R9127, R9211, R9212 RS1/16SS470J Not used
R9224, R9226, R9229, R9230 RS1/16SS470J Not used
R9236-R9238, R9242-R9244 RS1/16SS470J Not used
R9413, R9414, R9507, R9520 RS1/16SS470J Not used
R9523, R9525, R9532, R9535 RS1/16SS470J Not used
R9538, R9549, R9551, R9556 RS1/16SS470J Not used
R9562, R9567, R9579, R9610 RS1/16SS470J Not used
R9687 RS1/16SS470J Not used
R9422, R9426, R9428, R9431 RS1/16SS470J RS1/16SS0R0J
R9435 RS1/16SS470J RS1/16SS0R0J
R9122 RS1/16SS470J RS1/16SS680J
R9508, R9509, R9519, R9550 RS1/16SS472J Not used
R9559, R9568, R9570, R9591 RS1/16SS472J Not used
R9638, R9639, R9642, R9644 RS1/16SS472J Not used
R9645, R9647, R9648, R9650 RS1/16SS472J Not used
R9652 RS1/16SS472J Not used
R676, R677, R1830 RS1/16SS473J Not used
R9501-R9504, R9513, R9534 RS1/16SS473J Not used
R9541, R9543, R9546, R9552 RS1/16SS473J Not used
R9554, R9569, R9574, R9576 RS1/16SS473J Not used
R9578, R9580, R9584-R9586 RS1/16SS473J Not used
R9589, R9590, R9595-R9597 RS1/16SS473J Not used
R9599-R9603, R9606-R9609 RS1/16SS473J Not used
R9612 RS1/16SS473J Not used
R9657, R9658, R9661, R9663 RS1/16SS49R9F Not used
R1891 RS1/16SS680J Not used
R9105 RS1/16SS680J RS1/16SS470J
R9834 RS1/8SQ225J Not used
C1013, C9874 ACH7306 Not used
C634, C651, C1855, C9310 CCSSCH100D50 Not used
C1014 CCSSCH101J50 CCSSCH100D50
C1802, C1812, C9503, C9505 CCSSCH101J50 Not used
C9552 CCSSCH101J50 Not used
C173 CCSSCH102J50 CCSSCH100D50
C627, C646, C9535, C9542 CCSSCH102J50 Not used
C9567 CCSSCH102J50 Not used
C9336 CCSSCH270J50 Not used
C9037, C9038 CCSSCH471J50 CCSSCH330J50
C103, C1826, C1833, C1835 CCSSCH471J50 Not used
C1841, C9111, C9204, C9207 CCSSCH471J50 Not used
C9211, C9213, C9220, C9226 CCSSCH471J50 Not used
C9227, C9233, C9235, C9236 CCSSCH471J50 Not used
C9239, C9245, C9248, C9251 CCSSCH471J50 Not used
C9254, C9256, C9261, C9305 CCSSCH471J50 Not used
C9512, C9516, C9518, C9521 CCSSCH471J50 Not used
C9524, C9529, C9531, C9534 CCSSCH471J50 Not used
C9539, C9540, C9548-C9550 CCSSCH471J50 Not used
C9560, C9562, C9573, C9575 CCSSCH471J50 Not used
C9587 CCSSCH471J50 Not used
C1810, C1811 CCSSCH8R0D50 Not used
Mark Symbol and Description AWX9620 AWX9628 Remarks
