Pioneer sc-lx76 Service Manual

5
SC-LX86
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Notes : For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES".
> P79-11 Fuse (FU11, FU12, FU15 : 1.25A) REK1143 Not used Not used Not used
> P79-11 Fuse (FU11, FU12, FU15 : T1A) Not used AEK7073 AEK7073 AEK7073
> P79-12 Fuse (FU10 : 6A) REK1151 Not used Not used Not used
> P79-12 Fuse (FU10 : T5A) Not used AEK1061 AEK1061 AEK1061
P79-20 Insulator AMR7198 DXA1904 DXA1904 DXA1904
REAR SECTION
> P81-18 Fuse (FU4 : 2A) REK1139 REK1139 Not used Not used
> P81-18 Fuse (FU4 : 4A) Not used Not used REK1104 REK1104
> P81-19 Fuse (FU1 : 10A) REK1154 Not used Not used Not used
> P81-19 Fuse (FU1 : 10A) Not used DEK1045 Not used Not used
> P81-19 Fuse (FU1 : T5A) Not used Not used AEK1061 AEK1061
P81-22 Rear Panel ANC8643 ANC8651 ANC8652 ANC8653
P81-24 D MAIN Shield 85 ANK7162 Not used Not used Not used
P81-27 Nylon Rivet AEC7406 Not used Not used Not used
P81-28 Locking Spacer AEC7643 Not used Not used Not used
CHASSIS SECTION
> P83-12 Fuse (FU21, FU22, FU31, FU32 : 1.25A) REK1143 Not used Not used Not used
> P83-12 Fuse (FU21, FU22 : T800mA) Not used AEK7072 AEK7072 AEK7072
> P83-12 Fuse (FU31, FU32 : T1A) Not used AEK7073 AEK7073 AEK7073
FRONT SECTION
P85-19 Door Panel ANB7562 ANB7563 ANB7563 ANB7563
P85-23 Filter AAK8443 AAK8459 AAK8459 AAK8459
P85-24 Display Panel AAK8567 AAK8568 AAK8568 AAK8568
NSP P85-28 Panel Base AMB8041 AMB8042 AMB8042 AMB8042
P85-29 Panel ANB7582 ANB7586 ANB7586 ANB7586
P85-30 PIONEER Badge VAM1159 VAM1158 VAM1158 VAM1158
Mark No. Symbol and Description
SC-68
/UXJCB
SC-LX76
/FXJ
SC-LX76
/DLPWXJ
SC-LX76
/AXJ5
Remarks
