Pioneer SC-LX81 Service Manual

76
SC-LX81
1
2 3 4
A
B
C
D
E
F
1
2 3 4
PCB Assys and ICE Cover
3
1
1
Rear view
Disconnect the one flexible cable and five connectors.
2
1
Remove the one Push Rivet.
3
Remove the COMPONENT Assy.
COMPONENT Assy
PRIMARY Assy
ICE Cover 81
V-BRIDGE Assy CN7706 (FRONT BRIDGE ASSY)
ZOUT Assy AUDIO Assy COMPOSITE S Assy
3
1
×2
1
×2
2
×2
1
×2
1
1
×3
1
×2
1
1
2
2
COMPONENT Assy
Remove the two screws.
2
1
Remove the PRIMARY Assy.
PRIMARY Assy
Remove the seven screws.
2
1
Disconnect the two flexible cables and four connectors.
3
Remove the ICE Cover 81.
ICE Cover 81 Section
Disconnect the six flexible cables and two connector.
2
1
Remove the two Push Rivets.
3
Remove the AUDIO Assy, COMPOSITE S Assy,
V-BRIDGE Assy and ZOUT Assy.
AUDIO Assy, COMPOSITE S Assy, V-BRIDGE Assy
and ZOUT Assy
3
1
×7
2
2
2
×2
23
×2
