Pioneer VSA-AX10 Service Manual

VSA-AX10, VSX-AX10
7
AWX7944 and AWX7942 are constructed the same except for the following :
COMPOSITE ASSY
F
C
Mark Symbol and Description
Part No.
Remarks
AWX7942 AWX7944
IC2107 TC74HC4051AFT Not used
C2159,C2160,C2161 CKSRYB103K50 Not used
C2164 CCSRCH181J50 Not used
R2163,R2164,R2165 RS1/16S102J Not used
R2169 RS1/16S750J Not used
2105 2P PIN JACK AKB7076 Not used
JA2106 1P PIN JACK Not used AKB7142
COMPONENT ASSY
AWX7955 and AWX7953 are constructed the same except for the following:
Mark Symbol and Description
Part No.
Remarks
AWX7953 AWX7955
D2501 1SS355 Not used
R2572 RS1/16S102J Not used
J2504 AKN7014 Not used
F
AWX7952 and AWX7951 are constructed the same except for the following :
V-CONVERT ASSY
F
E
Mark Symbol and Description
Part No.
Remarks
AWX7952 AWX7951
IC2861 Not used TA8772AN
Q2855, Q2856 Not used 2SC4081(RS)
Q2857, Q2905 Not used UN5212
C2947, C2949, C2974 Not used CKSRYB103K50
C2950 Not used CEAT470M10
C2948, C2951- C2953, C2955, C2961- C2965 Not used CKSRYB104K16
C2980 Not used CKSRYB104K16
C2954 Not used CEAT100M50
C2956, C2957 Not used CKSRYB474K10
C2958- C2960 Not used CEAT1R0M50
C2975 Not used CEAT101M10
C2988 Not used CCSRCH100D50
L2855 LAU330J LAU270J
L2858 Not used LAU100J
R2868 RS1/16S911J RS1/16S821J
R2909 Not used RS1/16S103J
R2910- R2914, R2938, R2939 Not used RS1/16S102J
R2915 Not used RS1/16S362J
R2916, R2948 Not used RS1/16S473J
R2936, R2937 RS1/16S0R0J Not used
R2941, R2942 Not used RS1/16S153J
X2851 ASS1091 ASS1092
