Pioneer VSA-AX10 Service Manual

VSA-AX10, VSX-AX10
8
IC3901
BU4052BCF Not used Not used
D3901, D3902
UDZS6.2B Not used Not used
D3401 Not used RB501V-40 Not used
C3951, C3952 CEAT100M50 Not used Not used
C3953, C3954 CKSRYB473K50 Not used Not used
R3533, R3534 Not used RS1/16S105J Not used
R3543, R3544 Not used RS1/16S221J Not used
R3555, R3556 RS1/16S105J Not used Not used
R3951, R3952 RS1/16S472J Not used Not used
R3955- R3957 RS1/16S221 Not used Not used
R3958, R3959 RS1/16S0R0J Not used Not used
JA3502 2P PIN JACK Not used DKB1045 Not used
IC3061 TC74HC4053AFT Not used
Q3003 UN5212 Not used
Q3063 RN2903 Not used
D3029 SLI-343DUW(STU) Not used
D3062- D3064, D3066 1SS355 Not used
C3063 CKSRYB153K50 Not used
R3029 RS1/16S561J Not used
R3063 RS1/16S223J Not used
R3065, R3069 RS1/16S103J Not used
R3066 RS1/16S392J Not used
R3078 Not used RS1/16S0R0J
Mark Symbol and Description
Part No.
AWX7864 AWX7866
Remarks
DISPLAY ASSY
AWX7866 and AWX7864 are constructed the same except for the following:
F
M
Q1105 Not used 2SC2412K(QR) 2SC2412K(QR)
Q1106 Not used DTA124EK DTA124EK
D1107 Not used UDZ2.7B UDZ2.7B
D1108 Not used 1SS355 1SS355
R1107 RS1/16S104J RS1/16S473J RS1/16S473J
R1118, R1119 RS1/16S0R0J Not used Not used
R1120 Not used RS1/16S0R0J RS1/16S0R0J
R1121 Not used RS1/16S183J RS1/16S183J
T1101 ATT7043 ATT7040 ATT7041
CN1106 Not used B02B-XASK-1 B02B-XASK-1
Mark
Symbol and Description
Part No.
AWX7834 AWX7837 AWX7835
Remarks
AC PRIMARY ASSY
AWX7837, AWX7835 and AWX7834 are constructed the same except for the following:
A
B
F
Mark
Symbol and Description
Part No.
AWX7880 AWX7873
Remarks
ANALOG IN&A/D ASSY
AWX7880, AWX7873 and AWX7878 are constructed the same except for the following:
AWX7878
F
L
