Pioneer VSA-AX10 Service Manual

VSA-AX10, VSX-AX10
9
Q5805 2SC5174P Not used 2SC5174P
Q5806 RN4903 Not used RN4903
Q5809 UN5112 Not used Not used
Q5811 Not used RN4903 RN4903
Q5812 Not used RN1903 RN1903
Q5813 Not used 2SC5174P 2SC5174P
Q5814 Not used 2SA1932P 2SA1932P
D5801 UDZ11B Not used UDZ11B
D5808 Not used UDZ36B UDZ36B
D5809, D5816 Not used UDZ12B UDZ12B
D5810, D5812 Not used 1SS355 1SS355
D5811 Not used UDZS5.1B UDZS5.1B
D5813, D5818 Not used UDZ15B UDZ15B
C5801, C5802 CEJQ1R0M50 Not used CEJQ1R0M50
C5818 CEJQ100M16 Not used CEJQ100M16
C5819 CEAT101M16 Not used CEAT101M16
C5820 CKSRYB104K16 Not used CKSRYB104K16
C5851, C5854 Not used CEAT100M50 CEAT100M50
C5852, C5853 Not used CKSRYB103K50 CKSRYB103K50
C5858 CKSRYB103K50 Not used Not used
L5802 ATL7002 Not used ATL7002
R5814-R5818, R5820, R5821 RS1/16S0R0J Not used RS1/16S0R0J
R5891, R5893- R5897 RS1/16S0R0J Not used Not used
R5829 RS1/16S222J Not used RS1/16S222J
R5830 RS1/16S473J Not used RS1/16S473J
R5842 Not used RS1/16S104J RS1/16S104J
R5843, R5844 Not used RS1/16S394J RS1/16S394J
R5845, R5848 Not used RS1/16S101J RS1/16S101J
R5846, R5849 Not used RS1/16S471J RS1/16S471J
R5854 Not used Not used RS1/16S103J
R5855 RS1/16S103J Not used Not used
R5857 Not used RS1/16S103J RS1/16S103J
R5862 RS1/16S102J Not used Not used
R5864 RS1/16S104J Not used Not used
R5819, R5899, R5935 RS1/16S101J Not used RS1/16S101J
R5932 RS1/16S154J Not used Not used
CN5802 52045-1345 Not used 52045-1345
CN5826 Not used KM250MA3 KM250MA3
Mark
Symbol and Description
Part No.
AWX7890 AWX7895 AWX7892
Remarks
MOTHER ASSY
AWX7895, AWX7892 and AWX7890 are constructed the same except for the following:
F
R
