Pioneer VSX-417-S Service Manual

VSX-417-K
12
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
MULTI CH IN
SW
CN307
CN105
SL/SR
C
OPT1
CN1903
CN601
COAX2
COAX1
IC601
(DIR)
CD-R OUT
VCR/DVR OUT
(ADC)
LPF
(for DECODE)
DSPC56371AF180
DSP IC
CN701
CN109
IC104
(SW)
AK4114
IC801
(C)
IC103
IC104
(SL/SR)
AK4628AV0
(DIR+CODEC)
(DAC)
IC701
LFE MIX
IC105
(FL/FR)
IC107
DVD/LD
CD-R/TAPE
TV/SAT
L/R
L/R
L/R
CD
VCR/DVR
L/R
L/R
MODULE
TUNER
L/R
MAIN ASSY
A
DSP ASSY
B
DIGITAL
INPUT
ASSY
Q
5.1CH INPUT ASSY
H
PACK
ASSY
POWER

Pioneer VSX-417-S Specifications

General

Channels	5.1
Power Output	100 W
Output Power / Channel	100 W
Frequency Response	10 Hz - 100 kHz
Signal-to-Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Digital Sound Processor (DSP)	Yes
Surround Sound Effects	Dolby Digital, DTS
Surround System Class	5.1 Channel
Tuner Bands	AM / FM
Preset Station Qty	30
Amplifier Type	AV
Output Impedance / Channel	8 Ohm
Total Harmonic Distortion (THD)	0.08%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Video Inputs/Outputs	4 Inputs / 1 Output
Digital Audio Inputs	Coaxial digital input, optical digital input
Width	420 mm
Depth	347 mm
Height	158 mm
Total Harmonic Distortion	0.08%
