Pioneer VSX-D608 Service Manual

43
VSX-D608
Mark No. Description Part No.
Mark No. Description Part No.
SVIDEO ASSY
SEMICONDUCTORS
IC551,IC552 NJM2296D
IC553 TC4051BP
Q554 2SA1515
Q551 2SA933S
Q552 2SC1740S
Q553 2SC3377
D555,D556,D559,D560 1SS133
D557,D558 MTZJ6.2B
CAPACITORS
C570-C575 CCCSL221J50
C578,C579 CEAT470M10
C551,C555,C559,C563 CEAT470M25
C590,C591 CEAT470M25
C552,C556,C560,C564,C567 CGCYX104M16
C580-C582 CGCYX104M16
C553,C557,C561,C565 CGCYX473M16
C576,C577 CGCYX473M16
C584,C585,C587 CKCYF103Z50
C554,C558,C562,C566 CKPUYY103M16
C568,C569 CKPUYY103M16
RESISTORS
R583,R584 RS2LMF101J
Other Resistors RD1/4PU J
OTHERS
CN554 11P FFC CONNECTOR 52044-1145
CN552,CN553 AKP7020
4P MINI DIN SOCKET
CN551 4P MINI DIN SOCKET AKP7043
CN555 KR CONNECTOR 3P B3B-PH-K-S
FRONT VIDEO ASSY
CAPACITORS
C604,C608 CEAT470M25
C605-C607 CGCYX104M25
C603 CGCYX473M25
C609,C610 CKCYB471K50
C611,C612 CKCYF103Z50
RESISTORS
All Resistors RD1/4PU J
OTHERS
CN601 FRONT PIN JACK AKX7007
601 PCB BINDER VEF1040
DOLBY DIGITAL ASSY
SEMICONDUCTORS
IC9401 CS4226-KQ
IC9371 KM68V1002AJ-15
IC9201 NJM2100M
IC9602-IC9604,IC9701-IC9705 NJM4558MD
IC9501 PD5501B
IC9374 PDK038A
IC9391 PQ20WZ51
IC9151 TC74ACT151AF
IC9101 TC74HCU04AF
IC9311 TC74VHCT244AFT
IC9451 TC7SH08FU
IC9361 TC7WU04F
IC9601 TC9164AF
IC9321 XCC56362PV100
Q9201,Q9202,Q9601-Q9606 2SC3326
Q9203,Q9402,Q9607,Q9609,Q9610 DTA124EK
Q9204,Q9401,Q9608 DTC124EK
D9601,D9602 1SS181
COILS AND FILTERS
L9391,L9501,L9807,L9809 ATL7002
CHIP FERRITE BEAD
F9326,F9375,F9381 DTF1064
CHIP BEAD
L9101,L9102,L9151,L9311,L9361 QTL1013
CHIP SOLID INDUCTOR
L9402,L9403,L9451,L9801-L9805 QTL1013
CHIP SOLID INDUCTOR
CAPACITORS
C9334,C9365 CCSQCH100D50
C9341,C9349,C9355,C9357,C9358 CCSQCH101J50
C9373 CCSQCH101J50
C9300,C9301,C9304-C9307,C9309 CCSQCH221J50
C9314,C9316,C9366,C9368 CCSQCH221J50
C9387,C9388,C9390,C9399,C9400 CCSQCH221J50
C9422,C9428,C9429 CCSQCH221J50
C9108,C9154,C9505 CCSQCH271J50
C9127 CCSQCH471J50
C9104 CCSQCH560J50
C9159,C9201,C9202,C9324,C9326 CCSRCH101J50
C9329,C9336,C9338,C9340,C9345 CCSRCH101J50
C9348,C9386 CCSRCH101J50
C9736 CCSRCH102J50
C9363,C9364 CCSRCH150J50
C9420,C9707,C9708,C9721,C9722 CCSRCH151J50
C9735 CCSRCH151J50
C9408,C9409 CCSRCH180J50
C9360,C9405,C9424,C9554 CCSRCH221J50
C9609,C9610,C9621,C9622 CCSRCH221J50
C9362,C9629 CCSRCH271J50
C9411,C9426,C9427,C9452,C9508 CCSRCH471J50
C9601,C9602,C9605,C9606 CCSRCH471J50
C9613,C9614,C9617,C9618,C9625 CCSRCH471J50
C9639 CCSRCH471J50
C9105,C9109,C9151,C9312,C9372 CEJA101M10
C9383,C9393,C9402,C9501,C9801 CEJA101M10
C9410 CEJA1R0M50
C9713,C9714,C9727,C9728 CEJA220M25
C9739,C9740,C9803,C9805 CEJA220M25
O
P
Q
