5
XR-A880, XR-A770
(1) EXTERIOR (1/2) PARTS LIST
Mark No. Description Part No.
1 20P F.F.C/30V XDD3017
NSP 2 $M Mechanism CD XXA3005
3 Volume Knob XAA3005
4 FL Cover A XAK3026
5 FL Cover B XAK3036
6 Tray Cap XAK3019
7 Display Panel See Contrast table (2)
8 Bonnet Case XZN3040
9 Screw BPZ30P100FZK
10 Pioneer Badge XZN3049
11 Screw VBZ30P080FZK
12 Disc Label XAX3127
13 Jog Knob Assy XXG3023
14 Bass Knob XAB3005
15 Screw BCZ30P080FZK
16 Cord Stopper DNF1128
17 Push Rivet AEC7138
(2) CONTRAST TABLE
XR-A880/DBDXJ, DXJ/NC, XR-A770/DBDXJ and DXJ/NC are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A880 XR-A880 XR-A770 XR-A770
/DBDXJ /DXJ/NC /DBDXJ /DXJ/NC
7 Display Panel XAK3029 XAK3029 XAK3028 XAK3028
To Next Page
