7
XR-A880, XR-A770
(1) EXTERIOR (2/2) PARTS LIST
Mark No. Description Part No.
1 AF Assy See Contrast table (2)
2 SECONDARY Assy XWZ3137
3 PRIMARY Assy XWZ3111
4 FM/AM TUNER MODULE AXQ7065
5 Power Transformer (T1) XTS3018
6 Fuse (FU2, FU3 : T3.15A) AEK1059
7 Fuse (FU1 : 6.3A) REK1030
NSP 8 Chassis XNA3001
9 DC Fan Motor AXM7003
10 Fan Plate ANG7153
11 PCB Bracket XNG3006
12 • • • • •
13 Heat Sink XNH3004
14 Wire Clip A XEC3003
15 Rear Panel See Contrast table (2)
16 Cord Stopper DNF1128
NSP 17 SUPPORT Assy XNP3009
18 Screw BBZ30P140FMC
19 Screw VBZ30P080FZK
20 Tweeter Cover See Contrast table (2)
21 Screw ASZ40P060FMC
22 Binder ZCA-SKB90BK
23 • • • • •
24 Screw BPZ30P100FZK
25 Screw BBZ30P130FMC
NSP 26 Name Label See Contrast table (2)
27 Screw BBZ30P060FMC
28 Screw IBZ30P135FMC
29 SUB TRANS Assy XWZ3113
30 REAR AMP Assy See Contrast table (2)
31 TRADE Assy See Contrast table (2)
32 PRO LOGIC Assy See Contrast table (2)
33 H.S.Bracket XNG3007
34 FET Bracket XNG3009
35 H.S.Support XNG3014
36 Wire Clip B XEC3004
37 PCB Spacer B See Contrast table (2)
38 Mica Sheet XEE3002
39 Locking Spacer XEC3009
40 Card Spacer XEC3008
41 Push Rivet See Contrast table (2)
42 Shield Plate See Contrast table (2)
Mark No. Description Part No.
(2) CONTRAST TABLE
XR-A880/DBDXJ, DXJ/NC, XR-A770/DBDXJ and DXJ/NC are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A880 XR-A880 XR-A770 XR-A770
/DBDXJ /DXJ/NC /DBDXJ /DXJ/NC
1 AF Assy XWZ3128 XWZ3128 XWZ3106 XWZ3106
15 Rear Panel XNC3003 XNC3003 XNC3002 XNC3002
20 Tweeter Cover Not used Not used XAK3069 XAK3069
NSP 26 Name Label XAL3013 Not used XAL3010 Not used
30 REAR AMP Assy XWZ3160 XWZ3160 XWZ3108 XWZ3108
31 TRADE Assy XWZ3140 XWZ3140 Not used Not used
32 PRO LOGIC Assy XWZ3133 XWZ3133 Not used Not used
37 PCB Spacer B XEC3005 XEC3005 Not used Not used
41 Push Rivet AEC7069 AEC7069 Not used Not used
42 Shield Plate XNK3004 XNK3004 Not used Not used
To Next Page
