Pioneer XR-A770 Service Manual

9
XR-A880, XR-A770
(1) FRONT PANEL SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 DISPLAY Assy See Contrast table (2)
2 CD SW LED Assy XWZ3131
3 SUB DISPLAY Assy See Contrast table (2)
4 • • • • •
5 Cord With Plug DE007VE0
6 Flexible Cable 14P XDD3011
7 Flexible Cable 19P XDD3009
8 Flexible Cable 38P XDD3004
9 Connector Assy 3P XDE3013
10 Connector Assy 5P XDE3014
11 • • • • •
12 Mechanism Unit XYM3003
13 Door Spring L XBH3001
14 Door Spring R XBH3002
15 Latch Spring L ABH7130
16 Latch Spring R ABH7131
17 Screw BPZ30P100FZK
18 Latch Mold L XMR3001
19 Latch Mold R XMR3002
NSP 20 Jog Lens XAK3025
21 Damper Assy AXA7052
22 • • • • •
NSP 23 Front Panel Assy See Contrast table (2)
24 Function Button XZN3020
25 CD Button XZN3018
26 CD Lens XZN3037
27 Deck Lens L XZN3035
28 Deck Lens R XZN3036
29 • • • • •
30 Door Pocket L XZN3013
31 Door Pocket R XZN3015
32 Front Panel A XZN3011
33 Sub Panel A See Contrast table (2)
34 Power Button XZN3022
35 Play Button XZN3024
36 S.C. Button XZN3025
37 TIMER Button XZN3029
38 Sub Buttun XAD3012
39 Dolby Lens See Contrast table (2)
40 Diffusion Sheet XAK3035
41 Dolby Panel See Contrast table (2)
42 Button Lens See Contrast table (2)
NSP 43 Front Panel Assy B See Contrast table (2)
44 Sub Panel B See Contrast table (2)
45 Front Panel B See Contrast table (2)
46 Binder ZCA-SKB90BK
(2) CONTRAST TABLE
XR-A880/DBDXJ, DXJ/NC, XR-A770/DBDXJ and DXJ/NC are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A880 XR-A880 XR-A770 XR-A770
/DBDXJ /DXJ/NC /DBDXJ /DXJ/NC
1 DISPLAY Assy XWZ3130 XWZ3130 XWZ3109 XWZ3109
3 SUB DISPLAY Assy XWZ3132 XWZ3132 XWZ3112 XWZ3112
NSP 23 Front Panel Assy XXG3014 XXG3014 XXG3017 XXG3017
33 Sub Panel A XZN3031 XZN3031 XZN3044 XZN3044
39 Dolby Lens XAK3034 XAK3034 Not used Not used
41 Dolby Panel XAK3042 XAK3042 Not used Not used
42 Button Lens XAK3044 XAK3044 XAK3043 XAK3043
NSP 43 Front Panel Assy B XXG3027 XXG3027 XXG3026 XXG3026
44 Sub Panel B XZN3053 XZN3053 XZN3052 XZN3052
45 Front Panel B XZN3051 XZN3051 XZN3050 XZN3050
