Pioneer XR-MT3 User Manual

34
XR-MT3
Mark No. Description Part No.
Mark No. Description Part No.
CN206 FFC CONN SOCKET 16P 135-006116-160J
CN8 FFC CONN 6232 30PINS 135-006232-300J
CN205 FFC CONN SOCKET 24P 135-FEBTVK-240J
CN207 FFC CONN SOCKET 17P 135-TOCB17-171J
CN13 HSG PMT1-3A PEC 2001H 136-03PMT1-B00J
CN11 HSG PMT1-14A PEC 2001H 136-14PMT1-B00J
CX101 CRYSTAL RESONATOR 009-607200-000A
(7.2MHz)
CD SERVO PCB ASSY
SEMICONDUCTORS
IC2 (TA2065F) 010-832065-000A
IC3 (IC MOTOR DRIVER TA2092) 010-832092-000A
IC1 (TC9284BF) 010-849284-000A
IC4 BA4558N-HT
IC5,IC6 TA7291S
Q2 (TRLNPNPWR 3DA8050) 008-680500-000A
Q1 (TRLPNPPWR 3CA8550) 008-685500-000A
Q5 2SB562
Q6 2SC1815
D1-D3 1N4148
COILS
L1 (INDUCTOR 100µH) 018-010014-000A
L2 (BAD COIL #BA3534) 037-003534-100
CAPACITORS
C13,C19,C43 (CHIP CAP 24pF/50V) 003-624052-050A
C18 CCSRCH101J50
C57,C58 CCSRCH121J50
C52,C52,C59,C60 CCSRCH221J50
C15 CCSRCH270J50
C8 CCSRCH4R0C50
C37,C68,C12,C20 CEAT100M50
C34,C38,C40,C45,C61,C62,C54 CEAT101M10
C65 CEAT101M10
C42 CEAT102M10
C9 CEAT1R0M50
C27 CEAT220M25
C46,C48 CEAT221M10
C16,C31,C29 CEAT470M16
C72 CEAT471M10
C56,C55 CEAT4R7M50
C51 CEJQ101M10
C75 CEJQ470M16
C41,C4,C35,C22,C36 CGCYX104M16
C73,C47 CKCYF103Z50
C10,C11,C33,C74 CKSRYB103K50
C23,C24,C28,C64,C66,C69 CKSRYB104K16
C44 CKSRYB153K50
C26 CKSRYB223K50
C7,C6 CKSRYB332K50
C1 CKSRYB471K50
C21 CKSRYB472K50
C17,C30,C32,C3 CKSRYB473K16
C2 CKSRYB563K16
C14 CKSRYB682K50
C25 CKSRYF333Z50
RESISTORS
R34 RD1/4PM100J
R41 RD1/4PU101J
FEO,TEB,TEO (100kW) 002-104085-102A
Other Resistors RS1/16S J
OTHERS
21 ZENER IN-5232B 5.6V 011-010056-120A
FEB SEMI-FIXED 002-472065-000A
CN6 FFC CONN 6232 30P 135-006232-301J
CN3 FFC CONN SOCKET 16P 135-TOCA16-160A
CN1 HSG 5CD1-4B JST 136-045CD1-201J
CN5 HSG PMT1-4A JST 136-04PMT1-250J
CN4 HSG 2CD9-6C (REV) 136-067238-205J
CN2 HSG PMT1-8A JST 136-08PMT1-250J
SOLDERING PIN 137-300000-002J
X1 CERAMIC RESONATOR 020-001693-000A
(16.93MHz)
AMP PCB ASSY
SEMICONDUCTORS
IC251 (STK4142MKIIA) 010-554142-000A
IC202 BH3854FS
IC201 BU4052BC
Q255 008-680500-000A
Q257 008-801144-000A
Q251 2SA1015
Q201,Q252,Q253,Q256,Q262,Q264 2SC1815
Q258–Q261 2SD1468S
Q263,Q265 DTC114ES
D253,D255 011-024001-000A
D202,D203,D252,D252,D254,D256 1N4148
D257 1N4148
D201 MTZJ4.7B
D204-D206 MTZJ5.1B
D209 MTZJ9.1B
COILS
L251,L253 (INDUCTOR 10µH) 018-010016-202A
RELAY
RL291 RELAY 12V 128-122125-000A
CAPACITORS
C276,C277 (0.001µF) 004-010210-100
C271,C264 (MYLAR CAP 0.027µF) 004-027350-100
C257,C258 CCCSL150J50
C215 CEAT100M50
C226 CEAT101M10
C255,C256,C265,C266 CEAT101M25
C259 CEAT101M35
C213,C227 CEAT1R0M50
C214,C221,C228,C279 CEAT220M25
C203 CEAT221M16
C251,C253,C272 CEAT2R2M50
C261,C262 CEAT332M35
C216 CEAT3R3M50
C260 CEAT470M35
C212,C235 CEAT471M16
B
C
