Pioneer XR-MT3 User Manual

35
XR-MT3
Mark No. Description Part No.
Mark No. Description Part No.
C204,C210,C211,C216,C225,C233 CEAT4R7M50
C206,R204,R205 CEAT4R7M50
C220 CEATR22M50
C236,C237,C229 CGCYX104K25
C207,C209,C222-C224,C263,C280 CKCYB101K50
C252,C254 CKCYB471K50
C219,C232 CQMBA103J50
C267-C270 CQMBA104J50
C234 CQMBA223J50
C217,C218,C230,C231 CQMBA683J50
RESISTORS
R295,R296 RD1/2LMF101J
R265,R266 RD1/2LMF331J
R278,R279 RD1/2LMF4R7J
R212 RD1/4PU1R0J
R272,R281 RS1LMFR22J
Other Resistors RD1/4PM J
OTHERS
CN206 PUSH TERMINAL 118-000134-001A
CN204 HEADER 4 PINS 135-005267-090J
CN202 FFC CONN SOCKET 16P 135-006116-160J
CN201 HEADER CTL 3 PINS 135-PHS030-030J
CN208 HSG CD189D-3A 136-03189D-200J
P3,P4 ROUND PIN 137-500001-000J
TERMINAL/JACK PCB ASSY
SEMICONDUCTORS
IC901,IC902 BA4558N-HT
Q901,Q910,Q912,Q913 008-801144-000A
(TR DTA114YS)
Q904,Q906,Q907 2SC1815
Q902,Q903,Q905,Q908,Q909,Q911 2SD1468S
D901,D902 1N4148
CAPACITORS
C907 (CERAMIC CAP 0.02µF) 003-020380-050
C903,C910,C924,C925,C928,C929 CCCCH101J50
C908,C905 CEAT101M10
C902,C909 CEAT1R0M50
C935 CEAT220M25
C912 CEAT221M10
C927 CEAT2R2M50
C906,C904,C911,C913,C915-C918 CEAT4R7M50
C934 CEAT4R7M50
C914 CEATR22M50
C919 CGCYX104K25
C921-C923 CKCYF102Z50
RESISTORS
All Resistors RD1/4PU J
OTHERS
J201 CONN PIN 14 PINS 050-140060-200J
GND JP WIRE AWG22 140MM 051-275140-009J
J904 RCA JACK HSP-244V-01 118-000244-000A
J901 RCA JACK HTJ-032-09B 118-020032-003A
POWER PCB ASSY
SEMICONDUCTORS
IC306–IC308 124-010010-002A
(MICRO FUSE 251001 1A)
IC303,IC304 124-035010-000A
(MICRO FUSE #25103.5-TS2 3.5A)
D311 011-024001-000A
IC301 (IC REGULA BA09ST) 010-400009-001A
IC302 NJM78M56FA
Q302,Q303 (TRLPNPPWR 3CA8550) 008-685500-000A
Q301 2SC1815
Q304 DTC114ES
D305 (ZENER IN-5237B,8.2V) 011-010082-120A
D308 (ZENER BZX55C24 24V) 011-010240-120A
D312 (BRIDGE RECTIFIER RS602) 011-020602-001A
D306,D307,D309-D311,D313 011-024001-000A
(RECTIFIER IN-4001B)
D301-D304 (RECTIFIER IN-5401BL) 011-025401-000A
RELAY
RL301 RELAY 9 OSA-SS-212DM 128-090109-000A
COIL
L301 AC LINE FILTER 019-500160-000A
CAPACITORS
C316,C319 (CERAMIC CAP 0.01µF) 003-010320-250A
C313 (MYLAR CAP 0.01µF/100V) 004-010310-100
C310,C307 CEAT101M35
C318 CEAT102M16
C317,C301 CEAT221M16
C302 CEAT472M16
C320 CEAT4R7M50
C303–C306,C308,C309,C319 CKCYF103Z50
RESISTORS
R308 RD1/2PM475J
R304 RD1/2PMF221J
Other Resistors RD1/4PU J
OTHERS
SN302 CONN PIN 12 PINS 050-120060-251J
JP WIRE AWG22#UL1672 051-265160-003J
JP WIRE AWG22 YELLOW 051-275180-010J
AC CONTACT TERMINAL 137-400001-000J
F306 FUSE HOLDER 7900 550-790000-000J
P301 JP WIRE AWB22#1007 051-275120-009J
HEAT SINK 613PMT131000
SCREW BBZ30P060FMC
SCREW BBZ30P140FMC
CN301 HEADER 14 PINS 135-2001WS-140J
SN204 HSG PMT1-9A 136-09PMT1-C00J
