Pioneer XR-MT3 User Manual

36
XR-MT3
Mark No. Description Part No.
Mark No. Description Part No.
HP JACK PCB ASSY
SEMICONDUCTOR
D105 1SS133
COIL
L107 LAU100J
CAPACITORS
C287 CGCYX104M16
C280,C281 CKCYF103Z50
OTHERS
P201 JP WIRE AWG26 80MM 051-675080-009J
HP201 HEADPHONE JACK 116-008020-000
CN204 HEADER MOLEX 9 PINS 135-2001WR-040J
DISPLAY PCB ASSY
SEMICONDUCTORS
IC401 LC87F65C8A-QIP
Q406 2SC1815
Q402-Q405 DTC114ES
D401 1N4148
LED404-LED411 LED-Y-3MM 110-033045-013A
LED412 LED-R-3MM 110-033040-013A
LED401-LED403 LED-Y-3MM 110-033045-013A
SWITCHES
SW401-SW404,SW408-SW415 021-114165-000A
(F021-KHH902-001) TACT SW
SW405-SW407 021-114165-000A
(F021-KHH902-001)TACT SW
CAPACITORS
C416,C417 CCCCH220J50
C420,C428 CEAT100M50
C419,C418(CERAMIC CAP 30pF/50V) 003-430050-050
C407 (ELECT CAP 47000MFD/5.5V) 006-747300-05CA
C402,C404 CEAT1R0M50
C414 CEAT220M25
C405,C495 CGCYX104K25
C401,C403,C497-C499,C409-C413 CKCYF103Z50
C421,C415,C500 CKCYF103Z50
RESISTORS
RA404-RA406 001-220104-000A
RESISTOR NETWORK100K
RA403 RESISTOR NETWORK EXB 001-229103-000A
VR401,VR402 030-H12203-204A
Other Resistors RD1/4PU J
OTHERS
CN15 050-100050-201J
JP WIRE AWB22#1007 051-275120-009J
REM401 REMOTE/CONTROL PHOTO 111-000638-000A
LCD401 VACUUM FLUORESCENT 115-000920-000A
CN401 FFC CONN SOCKET 24P 135-FESTVK-240J
CN404 FFC CONN SOCKET 17P 135-TOCB17-171J
X401 CRYSTAL RESONATOR 009-332768-100A
(32.768kHz)
X402 CERAMIC RESONATOR 020-000800-000A
(8MHz)
G
F
