XR-MT3
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No.
1 AMP PCB Assy AUD-PMT1E
2 Screw BBZ30P060FMC
3 Screw KBZ30P060FNI
4 Screw BBZ30P140FMC
5 Screw BBZ40P060FMC
6 Screw BPZ20P050FMC
7 Screw BPZ26P080FMC
8 Screw BPZ30P100FNI
9 Screw CBZ30P060FMC
10 CD SERVO PCB Assy CD--PMT1E
11 • • • • • •
12 DISPLAY PCB Assy See Contrast table(2)
NSP 13 HP JACK PCB Assy • • • • • •
14 TERMINAL/JACK PCB Assy JK--PMT1E
15 Screw KBZ30P040FMC
16 Screw KBZ30P060FNI
17 CD DOOR Assy MT SUBPMT1DR01
18 POWER PCB Assy See Contrast table(2)
19 S-Assy PMT1 FP01 See Contrast table(2)
19 S-Assy PMT1 FP02 See Contrast table(2)
20 TUNER PCB Assy See Contrast table(2)
21 FFC Cable 16Pin 040160100101
22 FFC Cable 16Pin 040160260100
23 FFC Cable 17Pin 040170100100
24 FFC Cable 24Pin 040240200130
25 FFC Cable 30Pin 040300400100
26 Power TF EI35 120V See Contrast table(2)
26 Power TF EI35 230V See Contrast table(2)
26 Power TF EI35 11-2 See Contrast table(2)
27 Power TF EI66 120V See Contrast table(2)
27 Power TF EI66 230V See Contrast table(2)
27 Power TF EI66 11-2 See Contrast table(2)
28 Micro Fuse 251001 124010010002
29 Fuse #23901.6 (1.6A) See Contrast table(2)
29 Fuse #21801.6 (1.6A) See Contrast table(2)
30 Micro Fuse 251002 124020010002
31 Micro Fuse #25103.5 124035010000
32 PLA-ULP-6’06"-SP2NMG See Contrast table(2)
32 PLA-VDE-6’06"-VDG See Contrast table(2)
32 PLA-MOU-6’06"-BS6 See Contrast table(2)
32 PLA-JIS-6’06"-JIS See Contrast table(2)
33 CD MECHA,CMCJ 153000117000
34 Top Panel See Contrast table(2)
35 Direct Access Knob Lens 500PMT111000
36 Back Cover See Contrast table(2)
37 Power Standby Lens 500PMT129000
38 Fuse Insulation Cap 500623200000
39 CD Base Adaptor R 503PMT125000
40 CD Base Adaptor L 503PMT126000
41 Servo PCB Bracket 505PMT114000
42 FL Bracket 505PMT134000
43 LED Bracket 505PMT135000
44 PCB Mounting Bracket 505PMT136000
45 Volume Knob 510PMT103001
46 Clock Control Knob Set 510PMT108001
47 Direct Access Knob Set 510PMT109010
48 Side Panel-L 600PMT117001
49 Side Panel-R 600PMT118001
NSP 50 Bottom Tray 600PMT121000
51 Transformer Bracket 605PMT122000
52 FCC Cable HLD 605PMT142000
53 Cable Holder 605PMT143000
54 Power Heat Sink 613PMT124000
55 Heat Sink 613PMT131000
56 CD Shield Plate 650PMT139000
57 CD Insulation Sheet 650PMT144000
58 Display Filter Plate See Contrast table(2)
59 PC Sheet 650PMT149000
60 Transport Stopper PL 650PMT197010
61 Shielding Plate 650277225000
62 Rubber Foot 700PMT130000
63 Capacitor Boot 700PMT150000
64 Bushing See Contrast table(2)
65 Cable/Plastic Tie 727000100000
66 65 Label See Contrast table(2)
NSP 67 Trans. Stopper Label 809PMT194021
68 FCC Label See Contrast table(2)
NSP 69 Serial No Barcode Label See Contrast table(2)
70 Warning Label MT3KUC See Contrast table(2)
70 Warning Label MT3E See Contrast table(2)
70 Warning Label MT3D See Contrast table(2)
70 Warning Label MT3DL See Contrast table(2)
71 Back Label MT3KUC See Contrast table(2)
71 Back Label MT3MY See Contrast table(2)
71 Back Label MT3NV See Contrast table(2)
71 Back Label MT3DBD See Contrast table(2)
71 Back Label MT3DL See Contrast table(2)
72 Fuse Caution Label See Contrast table(2)
NSP 73 Front Panel 500PMT101001
NSP 74 GND. Copper Plate C 650PMT152000
NSP 75 GND. Copper Plate D 650PMT153000
NSP 76 GND. Copper Plate E 650PMT155000
NSP 77 Control Panel Plate 650PMT116010
NSP 78 Front Cover See Contrast table(2)
NSP 79 Display Lens 500PMT106010
NSP 80 Illuminated Ring 509PMT105000
NSP 81 CD Door 500PMT102001
NSP 82 CD Door Cover 600PMT120010
83 • • • • • •
84 PCB Insulation Sheet 650PMT157000
85 CD Caution Label See Contrast table(2)
NSP 86 Fuse Label See Contrast table(2)
87 Voltage Sel. Cover See Contrast table(2)
88 Voltage Sel. Knob See Contrast table(2)
NSP 89 Serial Label See Contrast table(2)
90 Tube AWG5 D4.72 L70 728000047L07
91 Tube AWG5 D4.72 L90 728000047L09
92 Tube AWG1 D7.35 L120 728000073L12
93 Tube AWG1 D7.35 L160 728000073L16
94 Tube AWG1 D7.35 L15 728000073L15
95 Ref Silver Label See Contrast table(2)
Mark No. Description Part No.
