Pioneer XR-MT3 User Manual

6
XR-MT3
12 DISPLAY PCB Assy DIP-PMT1E DIP-PMT1E-E DIP-PMT1E-E DIP-PMT1E-DL DIP-PMT1E-DL
18 POWER PCB Assy GEN-PMT1E-UL GEN-PMT1E-GA GEN-PMT1E-GA GEN-PMT1E-DL GEN-PMT1E-DL
19 S-Assy PMT1 FP01 SUBPMT1FP01 Not used Not used SUBPMT1FP01 SUBPMT1FP01
19 S-Assy PMT1 FP02 Not used SUBPMT1FP02 SUBPMT1FP02 Not used Not used
20 TUNER PCB Assy TUN-PMT1E-UL TUN-PMT1E-EU TUN-PMT1E-EU TUN-PMT1E-DL TUN-PMT1E-DL
26 Power TF EI35 120V 123113513020 Not used Not used Not used Not used
26 Power TF EI35 230V Not used 123183513140 123183513140 Not used Not used
26 Power TF EI35 11-2 Not used Not used Not used 1231D3513140 1231D3513140
27 Power TF EI66 120V 123516636021 Not used Not used Not used Not used
27 Power TF EI66 230V Not used 123586636142 123586636142 Not used Not used
27 Power TF EI66 11-2 Not used Not used Not used 1235D6636140 1235D6636140
29 Fuse #23901.6 (1.6A) 124016020001 Not used Not used Not used Not used
29 Fuse #21801.6 (1.6A) Not used 124016000002 124016000002 124016000002 124016000002
32 PLA-ULP-6'06"-SP2NMG 134117120108 Not used Not used Not used Not used
32 PLA-VDE-6'06"-VDG Not used 134220120001 Not used Not used 134220120001
32 PLA-MOU-6'06"-BS6 Not used Not used 134240120014 Not used Not used
32 PLA-JIS-6'06"-JIS Not used Not used Not used 134100120001 Not used
34 Top Panel 500PMT104001 500PMT104001 500PMT104001 500PMT148001 500PMT148001
36 Back Cover 500PMT113001 500PMT181000 500PMT181000 500PMT113001 500PMT113001
58 Display Filter Plate 650PMT147001 650PMT147002 650PMT147002 650PMT147002 650PMT147002
64 Bushing 700PMT156000 700PMT146000 700PMT146000 700PMT146000 700PMT146000
66 65 Label 809PMT194010 Not used Not used Not used Not used
68 FCC Label 809PMT194030 Not used Not used Not used Not used
NSP 69 Serial No Barcode Label 809PMT194040 809PMT194120 809PMT194090 Not used Not used
70 Warning Label MT3KUC 809PMT194050 Not used Not used Not used Not used
70 Warning Label MT3E Not used 809PMT194080 809PMT194080 Not used Not used
70 Warning Label MT3D Not used Not used Not used 809PMT194100 Not used
70 Warning Label MT3DL Not used Not used Not used Not used 809PMT194110
71 Back Label MT3KUC 809PMT196010 Not used Not used Not used Not used
71 Back Label MT3MY Not used 809PMT196020 Not used Not used Not used
71 Back Label MT3NV Not used Not used 809PMT196030 Not used Not used
71 Back Label MT3DBD Not used Not used Not used 809PMT196040 Not used
71 Back Label MT3DL Not used Not used Not used Not used 809PMT196050
72 Fuse Caution Label 809036380130 Not used Not used Not used Not used
NSP 78 Front Cover 600PMT119010 600PMT119020 600PMT119020 600PMT119010 600PMT119010
85 CD Caution Label Not used 809PMT194070 809PMT194070 809PMT194070 809PMT194070
NSP 86 Fuse Label Not used 809PMT194130 809PMT194130 809PMT194130 809PMT194130
87 Voltage Sel. Cover Not used Not used Not used 500PMT110001 500PMT110001
88 Voltage Sel. Knob Not used Not used Not used 510PMT112001 510PMT112001
NSP 89 Serial Label Not used Not used Not used 809000009000 809000009000
95 Ref Silver Label Not used 809PMT151000 809PMT151000 Not used Not used
Part No.
Mark No. Symbol and Description
KUCXCN MYXCN NVXCN DBDXCN DLXCN/NC
(2) CONTRAST TABLE
XR-MT3/KUCXCN, MYXCN, NVXCN, DBDXCN and DLXCN/NC are constructed the same except for the following :
