S-MT3W, S-MT3H, S-MT3, S-MT3-N
2
NOTES : Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Mark No. Description Part No.
PARTS LIST
Mark No. Description Part No.
SCHEMATIC DIAGRAM
For Packing
• S-MT3W • S-MT3H, S-MT3 and S-MT3-N
Mark No. Description Part No.
Mark No. Description Part No.
For Packing
• S-MT3W • S-MT3H, S-MT3 and S-MT3-N
I N
Red
Black with White Line
Black
White
I N
Red
Black
White
White
Speaker D87DC54-56F
Grille SMG1702
Screw SBA1187
Cable SDF1083
Catch SLH1068
Non-skid Pad SEC1485
Top Protector SHA2245
Bottom Protector SHA2246
Protection Mat SHC1762
Speaker D87DC54-56F
Grille SMG1700
Screw SBA1183
Cable SDF1084
Catch SLH1067
Top Protector SHA2243
Bottom Protector SHA2244
Poly Bag SHL1257
