ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
SPEAKER SYSTEM
RRV2344
T–ZZK JULY 2000 Printed in Japan
S-MT3W
XMD/UC
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach it by
pulling it toward you.
The speaker is attached to the baffle by 4 external screws. To
detach it, unfasten those screws. When attaching it, face its
terminal downward.
The input terminal is attached to the back board by press-fitting.
To detach it, pry it open by inserting a flat blade screwdriver into
lower side.
S-MT3H
XMD/EW
S-MT3
XMD/E
S-MT3-N
XMD/NC
This product is component of system.
65S
This service manual is intended for qualified service technicians; it is not meant
for the casual do-it-yourselfer. Qualified technicians have the necessary test
equipment and tools, and have been trained to properly and safely repair complex
products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability
of the product and may void the warranty. If you are not qualified to perform the
repair of this product properly and safely, you should not risk trying to do so and
refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals
which are known to the state of California to cause cancer, birth defects or other
reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
• S-MT3W
Component Model
Service
Remarks
manual
STEREO CD RECEIVER SYSTEM
X-MT2000
RRV2342
KUCXCN MYXCN,NVXCN DBDXCN DLXCN/NC
STEREO CD RECEIVER XR-MT3 XR-MT3 XR-MT3 XR-MT3 RRV2343
SPEAKER SYSTEM S-MT3W S-MT3H S-MT3 S-MT3-N RRV2344 This manual.
To Next Page
