Use a stud finder(not included) to
locate wood studs. Mark the edge
and center locations.
Position the arm assembly/wall
plate at your desired height and
line up the holes with your stud
center line. Level the wall plate
and mark the holes.
16in (406mm)
18-24in (609mm)
5A-2
5A-3
4
07
DO NOT overtighten.
Tighten only until snug.
01
c
d
a
b
a
e
e
f
01
For 18’’-24’’ Studs
Option B:
To Next Page
