Part# Description
1-A Porcelain-Coated Steel Upper Cooking Rack (x1)
2-A Porcelain-Coated Cast-Iron Cooking Grid (x2)
3-A Lid Stopper (x1)
4-A Flame Broiler Slider (x1)
5-A Flame Broiler Main Plate (x1)
6-A Spice Box (x1)
7-A Lid Handle Bezel (x2)
8-A Lid Handle (x1)
9-A Bottle Opener (x1)
10-A Main Barrel (x1)
11-A Hopper Assembly (x1)
12-A Flame Broiler Adjusting Bar Handle (x1)
13-A Flame Broiler Adjusting Bar (x1)
14-A Serving Tray Handle (x2)
15-A Serving Tray (x1)
16-A Side Shelf Handle (x1)
17-A Front Shelf Bracket / Left (x1)
18-A Front Shelf Bracket / Right (x1)
19-A Front Shelf (x1)
20-A Grease Bucket (x1)
21-A Bottom Shelf (x1)
22-A Wheel (x2)
23-A Support Leg / Front (x1)
24-A Support Leg / Back (x1)
25-A Support Leg for Wheel / Front (x1)
26-A Support Leg for Wheel / Back (x1)
27-A Screw (x26)
28-A Washer (x26)
29-A Locking Washer (x26)
30-A Screw (x2)
31-A Nut (x2)
32-A Wheel Axle Pin (x2)
33-A Wheel Washer (x2)
34-A Wheel Cotter Pin (x2)
35-A Screw (x2)
NOTE: Due to ongoing product development, parts are subject to change without notice.
