Page 3For technical questions, please call 1-888-866-5797.Item 56617
SAFETYOPERATIONMAINTENANCE SETUP
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Assembly Diagram on page 7.
Functions
U-Joint
Hydraulic Unit
Fluid Fill Plug
Safety Valve
Cover
DO NOT OPEN
OR ADJUST
Saddle
Handle
Handle Socket
Lift Arm
Rear Caster
Cover Plate
(remove
to access
Fill Plug)
Front
Wheel
Figure A:
