Pittsburgh 70262 - Description Qty

Page 7For technical questions, please call 1-888-866-5797.70262
Part Description Qty
1 Bearing 2
2 Screw Shaft 1
3 Saddle 1
4 Washer M10 2
5 Wing Nut M10 2
6 Bolt M8 x 65 2
7 Ratchet Tie-down 1
8 Nut M8 2
9 Bolt M10 x 45 2
10 Adjustable Frame 1
Part Description Qty
11 Bearing 2
12 Plate Assembly 1
13 Base Assembly 1
14 Nut M12 4
15 Washer M12 4
16 Caster Assembly 4
17 Bolt M10 x 50 2
18 Bolt M6 x 12 1
19 Spring Washer 2
20 Nut 2
Part Description Qty
21 Bushing 2
22 Bearing 1
23 Cotter Pin M3.2 x 36 1
24 Slotted Nut 1
25 Screw Rod 1
26 Nut M8 1
27 Set Screw M8 x 20 1
28 Bushing 1
29 Bearing 1
30 Socket 1
Parts List and Diagram
