Pkm EB-DKF-2 - Hob and control panel

39
3.1 Hob and control panel
HOB:
1
HOTPLATE 1 / Ø 180 mm / max. 2000 W
2
HOTPLATE 2 / Ø 140 mm / max. 1000 W
3
CONTROL PANEL (s. below)
CONTROL PANEL:
4
ROTARY KNOB FOR HOTPLATE 1
5
INDICATOR FOR HOTPLATE 1
6
ROTARY KNOB FOR HOTPLATE 2
7
INDICATOR FOR HOTPLATE 2
