Fiber Video Extension Module – Front View
Fiber Video Extension Module – Rear View
Air intake – keep clear
Fiber module
power switch
DC Power (4-pin mini-DIN)
for Fiber module
Input from the Quad Controller
USB 2.0
(Type-B connector)
SFP fiber transceiver connection output to the panel
