Unpacking the Box
© 2015 Planar Clarity Matrix Fiber Video Extension User Guide 7
Optional Accessories
Part Number Description
159-0055-00 10G OM3 50/125 micron multi-mode duplex Plenum fiber optic
cable – 20 m / 65.6 ft.
159-0054-00 10G OM3 50/125 micron multi-mode duplex Plenum fiber optic
cable – 30 m / 98.4 ft.
903-1474-00 Bulk Matrix multi-mode fiber cable – 1640 ft./500m spool.
159-0057-00 50 um multi-mode LC Unicam, OM3 pre-polished fiber connector –
1 piece.
159-0058-00 Connector trigger, narrow pitch. Used to create a duplex connector
using 2 159-0057-00 single connectors.
541-0139-00 Pre-polished kit for field termination of multi-mode and single-
mode LC, SC and ST® compatible connectors. Includes precision flat
cleaver, 1.25 and 2.50 mm VFL ferrule adapters and all required fiber
preparation, cleaning tools and materials.
175-1068-00 Cable Assy, PWR, AUX, TOUCH. Used to connect the optional touch
sensor to the LCD panel for DC power.
