Planar LC1503R - Color and Image Menu Items

LC1503R/LC1503R‐CUser’sGuide

15
ColorMenu: 
 Auto‐Color:Configurethedisplaytomaintainoptimalcolorconfiguration
automatically.

 StandardRGB:ConfigurethedisplayusingthesRGBcolorspacestandards.

 ColorTemperature:Bringsupthefollowingsub‐menuitems.

 UserMode(Default):UserconfigurableRGBsettings.

  ColorTemperature6500K:Astandard“warm”colorscheme.

  ColorTemperature9300K:Astandard“cold”colorscheme.

  Exit:Exitthissub‐menuandreturntotheColorMenu.

 Exit:Exitthissub‐menuandreturntothemainOSDmenu.


ImageMenu: 
 Auto‐Adjust:Configurethedisplaytoautomaticallydeterminetheoptimal
horizontal/verticalfrequencies.

 Clock:Manuallyadjusttheclock/pitchcontrols toeliminateverticalbanding.(Note:
Thedisplaywillbe‘wider’whenusingthisfunction.)

 Phase:Manuallyadjustthephasecontrolstoeliminatehorizontalstreaking.

 HorizontalPosition:Adjustthehorizontal
locationoftheimageonthedisplayby
usingtheleft/rightadjustments.

 VerticalPosition:Adjusttheverticallocationoftheimageonthedisplaybyusingthe
left/rightadjustmentstomovetheimagedown/up.

 Exit:Exitthissub‐menuandreturntothemainOSDmenu.

